Power: 10W, 18W, 22W, 44W
Luminous Flux: 959lm - 5,852lm
Luminous Efficacy: 96lm/W - 143lm/W
Color Temperature: 3000K, 4000K, 5000K, 6000K
Length: 2ft, 4ft
CRI: ≥80
Beam Angle: 93°
Power Supply: Mounted
Input Voltage: 100-277V AC ~ 50/60Hz
Power Factor: ≥ 0.9
Dimmable: No
Housing Material: Aluminum
Lens Material: Polyacrylate
Finish: Black, White
Ambient Operating Temperature: -25°C ~ +45°C / -13°F ~ +113°F
Lifetime: ≥ 50,000hrs
Quantity:
Applications
Certifications
Photometrics
Downloads
SPECIFICATION SHEET
v. 1.0
INSTALLATION GUIDE
v. 1.3
IES FILES, zipped
qty 27
Specification Table
LB-1010A
959lm - 1,020lm
107lm/W - 113lm/W
XXX
2ft
2.65lbs
LB-1018A
1,624lm - 1,728lm
96lm/W - 102lm/W
XXX
2ft
2.65lbs
LB-1018B
1,794lm - 1,908lm
106lm/W - 112lm/W
XXX
4ft
4.41lbs
LB-1022B
2,089lm - 2,222lm
99lm/W - 106lm/W
XXX
4ft
4.41lbs
LB-1044B
4,177lm - 4,444lm
102lm/W - 108lm/W
XXX
4ft
4.41lbs
LB-1044B2
5,852
143lm/W
AAA
4ft
4.41lbs
